Electronic Wheel Balancer LAUNCH WA613

Electronic Wheel Balancer LAUNCH WA613 Electronic Car Scale is an innovative device designed to meet the needs of maintenance workshops and service centers with high efficiency and accuracy. This device features modern technologies that ensure precise measurements even with heavy weights, in addition to its practical and durable design that withstands intensive use. Whether you’re looking to enhance work efficiency or improve service levels, the LAUNCH WA613 is the perfect solution to achieve that.

Introduction to Electronic Wheel Balancer LAUNCH WA613

The LAUNCH WA613 Car Scale is a 3D wireless electronic scale with an innovative and modern industrial design. This device is used to measure the relative positions and angles between a vehicle’s wheels, helping to accurately determine the wheel weight parameters.

Main Purpose: The WA613 assists technicians at service centers in adjusting wheel weight parameters to meet the vehicle design requirements. This ensures smooth and safe driving while reducing fuel consumption and tire wear. The device also stands out for its ease of use, as it is unaffected by the leveling of the work platform or the tilt of the vehicle body, ensuring accurate measurements under various conditions.

The device offers dynamic measurement capabilities through the motion or rotation of the vehicle’s wheels. This approach improves the efficiency and accuracy of the measurements, saving both time and effort.

Measurement Range Table and Vehicle Specifications Support:

Operating Environment Requirements Table:

Features of the Electronic Wheel Balancer LAUNCH WA613

• Ready to Use Immediately: The Electronic Wheel Balancer LAUNCH WA613 car balance device comes pre-assembled and calibrated from the factory, meaning there is no need for assembly or wiring. The device is ready for immediate use, saving time and effort in setup.
• Compatibility with Multiple Platforms: The device is compatible with various platforms, including large cross lifts and four-post lifts, offering flexibility to adapt to workshop needs.
• Wireless Data Transmission: Equipped with the ST13 smart data connector, the device transmits measurement data wirelessly. You can monitor the measurement process and results at any time, making chassis adjustments easier.
• High-Capacity Battery: The device features a high-capacity battery and does not require connection to a power source during the measurement process, making it safer and easier to use.
• Supports Two Measurement Methods: The WA613 electronic car balance supports two alignment measurement methods: standard measurement and quick measurement. It can measure basic parameters such as toe-in, camber, caster, kingpin inclination, and thrust angle. It also supports additional measurements like wheelbase, track width, axle offset, wheel offset, diagonal, and center offset.
• Supports Over 50,000 Global Vehicle Models: The electronic car balance covers alignment data for over 50,000 global vehicle models and supports user customization, making it suitable for various cars from different brands and models.
• Professional Reporting: The WA613 generates professional inspection reports, allowing you to compare data before and after adjustments. It also supports report sharing, facilitating communication with clients or technical teams.

Features of the Electronic Wheel Balancer LAUNCH WA613

• High measurement accuracy: Provides precise results for measuring vehicle weights, ensuring reliability and dependability.
• Sturdy and high-quality design: Built to withstand heavy loads and intensive use in tough work environments.
• Advanced and modern technologies: Utilizes the latest technologies to ensure stable performance and ease of use.
• Easy to use: Features a simple interface that allows users to operate the device easily without complications.
• Versatile: Suitable for various types of vehicles, making it ideal for maintenance centers and workshops.
• Comprehensive technical support: Comes with a warranty and technical support for assistance when needed.
• Time and effort efficiency: Helps improve workflow in workshops and increase productivity.
• Competitive price: Offers high value for the cost, making it an ideal investment for automotive workshops.
• Innovative design that fits all types of workshops: Combines functionality and elegance in design.
• Easy maintenance and repair: Designed for easy maintenance with readily available spare parts.
• Reliable warranty: Comes with a comprehensive warranty that covers manufacturing defects for peace of mind.
• Integration with other electronic systems: Can be connected to maintenance systems or workshop management software to enhance performance.
• Resistant to environmental factors: Made from materials that withstand humidity and dust to ensure long-lasting durability.
• Quick measurement response: Displays results immediately to save time during work.
• Low energy consumption: Designed to work efficiently without consuming excessive energy.
• Compact and convenient design: Easy to transport and install in different workspaces.
• Clear digital display: Facilitates accurate data reading, even in low-light conditions.
• Capability to measure weights accurately for both heavy and light vehicles: Supports a wide range of weights to meet diverse needs.

What is the best electronic wheel balancer for cars?

If you are looking for an advanced device to measure wheel alignment in your workshop, the LAUNCH WA613 is the perfect choice. This device features modern technology that provides exceptional accuracy in wheel alignment measurements, ensuring accurate and reliable results every time. With its wireless 3D design, you can obtain quick measurements without the hassle of dealing with wires or worrying about the device being affected by body tilt or floor level.

The LAUNCH WA613 electronic wheel balancer is easy to use, thanks to its smart interface that allows you to monitor the measurement process continuously. It is also compatible with various types of lifts, making it suitable for different car workshops. The device supports a wide range of measurements, including wheel angle and toe, making it ideal for meeting the needs of your workshop with the highest level of efficiency.

In addition, the LAUNCH WA613 wheel balancer comes with a long-term warranty and excellent technical support services from Launch Saudi Arabia, the authorized distributor of Launch products in the Kingdom. With this device, you will be able to enhance your workshop’s performance by obtaining accurate results quickly and efficiently, saving you time and cost while providing high-quality service to your customers.

Why choose the LAUNCH WA613 electronic wheel balancer for car workshops?

• Exceptional Accuracy: The LAUNCH WA613 wheel balancer provides precise measurements of vehicle weights, enhancing the accuracy of maintenance services and reliability.
• High Dependability: With its robust design and modern technology, the device withstands daily intensive use without affecting its performance.
• Ease of Use: Featuring a simple user interface, it allows technicians to perform measurements quickly and easily, even in busy work environments.
• Suitable for All Types of Vehicles: The LAUNCH WA613 is capable of measuring the weight of both light and heavy vehicles, making it ideal for various types of workshops.
• Time and Work Efficiency: It helps reduce the time spent on weight measurements, boosting workshop productivity and increasing customer satisfaction.
• Competitive Price: Offers excellent value for the cost, with high quality and long-term performance.
• Comprehensive Technical Support: 24/7 technical support is available to assist when needed, along with maintenance services and spare parts.
• Advanced Technology: Built on the latest innovations to ensure stable performance and measurement accuracy.
• Environmentally Resistant Design: The device can endure harsh conditions such as dust and humidity, making it suitable for use in all types of workshops.
• Reputable LAUNCH Brand: As a product of the global Launch company, it combines innovation and quality recognized by professionals worldwide.

Choosing the LAUNCH WA613 electronic wheel balancer is an investment in improving work quality and increasing workshop efficiency, ensuring the best services for your customers.

Instructions for Using the LAUNCH WA613 Electronic Wheel Balancer

The diagram below shows the coordinated operating layout of the LAUNCH WA613 wireless 3D wheel balancer. The entire system mainly consists of a data collection section and the ST13 smart connection device. The data collection section is made up of two measurement units and four targets.

Explanation:

Important Note: In this explanation, we aim to help you understand what the LAUNCH WA613 electronic wheel balancer is. However, we take no legal responsibility for any misunderstanding of the explanation, application, or any unforeseen issues that may occur with the device or individuals. Please do not attempt to install the device yourself; let professionals do it instead. If the device is from Launch Saudi Arabia, we will install it for you.

• Data Collection Section: This part is responsible for measuring and processing wheel alignment data. It contains two measurement units that gather data related to the location and angles of the wheels. It also includes four targets used to precisely locate the wheel centers during the measurement process.
• ST13 Smart Connection Device: This device transmits data from the measurement units to the main system, allowing you to monitor the results in real-time. The device is user-friendly and connects wirelessly, enhancing the efficiency of the measurement process.

The entire operation works in perfect coordination between all parts to ensure accurate and quick measurements.

Structure of the WA613 Electronic Wheel Balancer

General Structure

The WA613 wireless 3D wheel balancer consists mainly of several key components, including:

• Measurement units (right/left)
• Clamps and targets (front right side, front left side, rear right side, rear left side)
• ST13 smart connection device
• Rotating kits
• Steering wheel holder
• Brake pedal holder

All of these are connected to a standard four-column lift.

Note: Products with different configurations contain different components and accessories. It is advised to consult with the distributor or refer to the product packing list for precise details.

Assembly of the Measurement Unit

The WA613 device has two measurement units (right/left), which are responsible for accurately measuring data related to the position and angles of the wheels.

Clamp and Target

In the WA613 wireless 3D wheel balancer, the terms “clamp” and “target” refer to the components used to secure and perform precise measurements on the vehicle’s wheels.

Clamp:

The clamps are devices that are attached to the wheels during the measurement process. They are used to ensure that the reference unit or target remains fixed during measurement, helping to achieve high measurement accuracy. Four clamps are used in this device:

• Front Right Clamp (FR)
• Front Left Clamp (FL)
• Rear Right Clamp (RR)
• Rear Left Clamp (RL)

Target:

The target is a device that is attached to the wheel in such a way that the measurements are based on these targets. These targets are linked to the reference units, which measure the angles and dimensions of the wheels accurately. The targets are used to measure various angles such as wheel toe, camber angle, thrust angle, and others.

These components (clamps and targets) play a vital role in ensuring measurement accuracy and the ability to correctly collect the required data during the wheel alignment process.

Steps to Operate Four-Wheel Alignment

Preparations Activating the Device

When using the WA613 electronic wheel balancer for the first time, it is essential to activate the device via the inspection device (the ST13 smart linking device).

Note: Before activating the device, ensure that the WA613 wheel balancer is in a normal startup state, and that the inspection device (ST13 smart linking device) is attempting to connect (i.e., the measurement unit is flashing a blue light).

1. Enter the main interface of the four-wheel alignment measurement program by clicking on the [Four-Wheel Alignment] application on the inspection device.
2. Click the [Four-Wheel Alignment] icon in the main interface to access the device activation interface, select the device, then click [Activate].

3.Enter the serial number and activation code for the WA613 electronic wheel balancer, then click [Activate].

4.Activated successfully

5.Select the device and click [Next].

Using Positioning Stickers

The electronic car wheel alignment scale comes with positioning stickers to assist in the installation of the device. The positioning sticker should be placed approximately 1 cm from the surface of the lift, ensuring that the surface of the sticker is parallel to the lift’s surface.

Routine Inspection

Enter the main interface of the four-wheel alignment measurement program by clicking on the [Four-Wheel Alignment] application on the inspection device. The main interface displays six functions:

1. Four-Wheel Alignment
2. Quick Inspection
3. Inspection Records
4. Database
5. Device Management
6. System Settings

Car Selection

Click on the [Four-Wheel Alignment] icon in the main interface to enter the routine four-wheel alignment inspection interface, then select the car first. Based on the vehicle information to be inspected, select [Region] -> [Brand] -> [Model] -> [Year] -> [Configuration] in sequence, then proceed to the [Vehicle Information] interface.

Note: You can enter the relevant information in the search box at the top of the screen for quick search.

In the “Vehicles” interface on the car scale screen, you can view the standard data for the car, and you can also modify the configuration and add custom data as needed.

Car Inspection

After selecting the vehicle in the “Vehicles” interface on the electronic car scale, you can begin the four-wheel alignment inspection process. The inspection involves measuring the angles of the wheels and other factors that affect the vehicle’s performance during driving. The different components of the WA613 electronic car scale, such as the measuring units and targets, are used to accurately measure wheel alignment.

The inspection results will be displayed immediately on the inspection device, allowing you to review them and take necessary actions to adjust the alignment if needed.

Completing Relevant Vehicle Inspections

Complete the necessary vehicle inspections, such as checking the tires, tire tread, tire pressure, and measuring the vehicle height, then click [Next] to enter the measurement setup interface. You can also click [Skip Vehicle Inspection] to enter the measurement setup interface without performing the vehicle inspection.

Tire Inspection

After checking the tread condition, click the [+] button, select the tread condition options for each tire in the pop-up window, and you can attach corresponding reference images (up to 3 images). After completing the tire inspection, click [Next] to enter the “Tread and Tire Pressure Inspection” interface.

Tread and Tire Pressure Inspection

After completing the tread and tire pressure inspection on the car’s electronic wheel alignment system, click the corresponding input box in this interface to enter the inspection values. Under the “Tread Depth” option, you can click [+] or [-] to increase or decrease the input value to match the number of grooves for different types of tires (from 2 to 5). Here, you can click [Tread Inspection Tool] to connect to the corresponding tread inspection device (sold separately) for tread checking.

After completing the tread and tire pressure inspection, click [Next] to enter the “Vehicle Height Measurement” interface.

Vehicle Height Measurement

Follow the on-screen instructions to check the vehicle’s body height and enter the measured value in the corresponding input box. The specific steps are as follows:

1. Fill the vehicle with fuel, coolant, and lubricants, and place the spare tire and tools in their designated locations.
2. Use a tape measure to measure the vehicle height (H) using the method shown in the figure below.
3. Enter the measured value (H) in the corresponding input box.
4. When all values are green, the vehicle height conforms to the standards; if one or more values appear red, a check and troubleshooting of the vehicle will be necessary. After completing the vehicle height measurement, click [Next] to enter the “Measurement Setup” interface.

Measurement Setup

Install the stabilizer and device according to the on-screen instructions, then perform the measurement scan.

Installing the Stabilizer

Follow the instructions displayed on the screen of the car wheel alignment scale to properly install the stabilizer. After installation, you can start the measurement scan to obtain accurate results.

Click on [Install Stabilizer] and install the relevant stabilizers according to the instructions displayed on the screen.

Follow the instructions below to install the stabilizers:

1. Align the front wheels of the car with the center of the rotating table.
2. After securely parking the car on the lift, attach the wheel brakes to the rear wheels to prevent slipping.
3. Align the front wheels, lock the steering wheel, place the gear lever in neutral, and release the parking brake.

Installing the Device

After completing the stabilizer installation, click [Next] to enter the electronic car scale device installation guide interface, then install the device according to the instructions displayed on the screen.

1. Installing the Clamps

Please align the clamps with the center of the tire according to the diagram. Attach the 4 clamp jaws to the metal rim of the tire, directing the decorative side of the target toward the center (measurement unit).

2. Installing the Measurement Unit

Please install the measurement unit between the front and rear clamps, and secure the magnetic surface from top to bottom on the side of the lift bridge.

3. Aligning the Measurement Unit

To ensure that the two measurement units are aligned with each other, visually check that one unit is on the same longitudinal axis as the corresponding unit.

After installing the clamps and measurement units, the lights on the measurement units will blink quickly in blue, indicating that the units are searching for the ST13 smart connection device. Then, the lights will blink slowly in blue, indicating that the device is establishing an internal network. Once both measurement units are successfully connected to the tester device, the lights will remain steady green.

Advanced Technologies in the LAUNCH WA613 Wheel Alignment Scale for Accurate Weight Measurement

The LAUNCH WA613 electronic wheel alignment scale is equipped with advanced technologies that ensure high precision and efficiency in measurements. Here are some of the key technologies:

• Wireless Technology: The device uses wireless communication technologies to transmit data quickly and securely between the different units and the ST13 tablet, allowing for accurate measurements without the need for wires, reducing the risk of interference or disruption.
• 3D Measurement: The device utilizes 3D measurement technology to obtain precise data on wheel alignment, ensuring better vehicle performance and reducing uneven tire wear.
• Independent Operation: The device is powered by a high-capacity battery, allowing it to operate independently without the need for continuous connection to a power source, making it safer and more flexible for use in workshops.
• High Measurement Accuracy: The device features an advanced system for measuring angles and alignment changes, such as front and rear angles and side wheel measurements, ensuring measurement precision down to fractions of a degree.
• Compatibility with Various Platforms: The device can be used with multiple types of lifts (such as four-column lifts and mobile platforms), making it adaptable to various workshop environments.
• Ease of Use and Installation: The device is designed for easy installation and use, with an intuitive interface on the ST13 for easy interaction with test reports and adjustment of measurements.
• Customization and Multi-Model Support: The device supports over 50,000 car models worldwide, with the ability to customize data according to the specific requirements of each car or wheel type.
• Advanced Data Analysis: The device provides detailed reports on wheel alignment measurements, supporting the comparison of data before and after adjustments to ensure quality and accuracy of modifications.
• Environmental Interference Protection: The WA613 device is equipped with technologies that protect it from environmental factors, ensuring accurate performance in various conditions without being affected by weather changes or elevation.
• Easy Maintenance and Updates: The device provides regular updates and maintenance guidance through the smart system, helping to maintain its high performance for an extended period.

These advanced technologies make the LAUNCH WA613 the ideal choice for workshops and specialized automotive maintenance centers, ensuring time and effort savings while maintaining accurate results.

Buy LAUNCH WA613 Automotive Wheel Alignment Electronic Scale at Competitive Prices

If you’re looking for an accurate and reliable electronic scale for measuring wheel alignment, the LAUNCH WA613 is the ideal choice for you. Launch Saudi Arabia, the authorized distributor for Launch products in Saudi Arabia, offers this advanced device at the best competitive prices in the market.

Benefits of buying the device from Launch Saudi Arabia:

• Best Price: We offer competitive prices to ensure you get value for your money.
• Best Warranty: Launch Saudi Arabia provides a long-term warranty on the device, ensuring peace of mind.
• Excellent Technical Support: Our trained technical team is always ready to provide support and answer your inquiries.
• Professional Installation: We offer device installation services in your workshop by specialized technicians to ensure the device works efficiently.

Get the LAUNCH WA613 Automotive Wheel Alignment Electronic Scale now from Launch Saudi Arabia and enjoy advanced technologies and high accuracy in wheel alignment measurement with the best after-sales service.

Customer Experiences with the LAUNCH WA613 Automotive Electronic Scale

Review:
“I decided to buy the LAUNCH WA613 automotive electronic scale for my car maintenance workshop in Riyadh after hearing many positive reviews. The experience was amazing from the moment we started using the device. The accuracy of the measurements exceeded my expectations, and the wireless communication technology made the process much easier. The device is very fast in providing results, which helped us improve efficiency in our workshop. In addition, the technical support service from Launch Saudi Arabia was excellent, the device was installed easily, and they guided us on how to use it properly. I highly recommend this device to any workshop looking for accuracy and efficiency in wheel alignment measurement.”
Name: Abdullah Al-Otaibi
City: Riyadh

Review:
“I purchased the automotive electronic scale from Launch Saudi Arabia for my car workshop in Jeddah, and the result was amazing! The device is easy to use, and its smart interface made the measurement process simple and quick. I was especially impressed with the accuracy of the measurements provided by the device, which helped improve vehicle performance and reduce uneven tire wear. Additionally, the WA613 is compatible with many lifts, which is important in our workshop that uses multiple lifts. The customer service and technical support from Launch Saudi Arabia were excellent, and the device was installed without any issues. The device is an excellent investment, and I am grateful for this experience.”
Name: Fahd Al-Shahrani
City: Jeddah

Review:
“After deciding to upgrade my maintenance workshop in Dammam, I chose the LAUNCH automotive electronic scale from Launch Saudi Arabia based on many recommendations. The device is easy to install and use, and it was great that I didn’t face any difficulties in making the measurements thanks to its simple and smart interface. The measurement results were very accurate, and it helped me improve the quality of service we provide to customers. Moreover, the WA613 device was perfect for our workshop, as it works excellently with the four-column lifts we use. The technical support team from Launch Saudi Arabia was very helpful in case I had any questions. I would definitely recommend it to anyone who owns a car workshop and wants an accurate and reliable device.”
Name: Ahmed Al-Zahrani
City: Dammam

FAQs about the LAUNCH WA613 Automotive Electronic Scale for Wheel Alignment

• What is the LAUNCH WA613 Automotive Electronic Scale?
  The LAUNCH WA613 is a wireless 3D automotive wheel alignment scale used to determine the positions and angles of wheels in cars, helping adjust wheel alignment for smooth and safe driving.
• Does the WA613 automotive scale require complicated installation?
  No, the WA613 is easy to install and does not require assembly or wires. It is easily activated using the smart ST13 scanner.
• Does the device need calibration before use?
  No, the LAUNCH WA613 automotive electronic scale does not require factory calibration, and it comes ready for use without the need for prior adjustments.
• Can the WA613 device be used with all types of lifts?
  Yes, the WA613 automotive scale is compatible with multiple platforms and can be adapted for use with large lifts and four-column lifts.
• Can the WA613 device be used to check different types of cars?
  Yes, the LAUNCH WA613 automotive electronic scale supports wheel alignment data for over 50,000 car models worldwide, with the ability to customize the user data.
• Does the device require continuous connection to electricity?
  No, the device is equipped with a large-capacity battery, meaning it does not need to be connected to electricity during the measurement process.
• Does the device provide inspection reports?
  Yes, the WA613 automotive scale provides professional inspection reports, with the ability to compare data before and after adjustments and supports report sharing.
• Can the measurement data in the WA613 device be customized?
  Yes, you can add custom data and modify configurations based on specific vehicle inspection requirements.
• Are the front and rear wheels inspected separately?
  Yes, clamps are installed on all the front and rear wheels, and alignment is measured accurately for each wheel separately.
• Does the WA613 automotive scale need constant inspection?
  Periodic checks are recommended for the device to ensure measurement accuracy.
